RS-140 BAND SEALER

The RS140 is a continuous rotary band sealer that will seal a wide range of plastic bag materials  such as nylon, polypropylene, laminates, tyvek/polyester and foil at a high speed and utilizes a 2" rotary blade to trim off the top of each bag.

The sealer features an adjustable stand with locking casters and has a crank wheel for height adjustments on the sealer which enables multiple bags size applications.

The sealer is designed with a 5" heating and 5" cooling zone which makes it effective for sealing difficult materials with a PID temperature controller range up to 200șC and variable speed controller up to 600 inches per minute..

RIQTECH
ROTARY BAND SEALING MACHINES Manufacture in Scarborough Ontario Canada
BAND SEALER

The RS140 delivers seals with the use of special heavy duty wear-tear resistant PTFE laminated Teflon bands. The variable speed sealing head and variable speed lower conveyor makes it easy to synchronize speed. This sealer is available in left to right or right to left feeding direction and comes with a 1/4" standard seal width (1/8",1/4",3/8" and 7/16" seal width are also available).
Electrical 110 VAC , 6 amps/ 60 Hz. No compressed air required.


Custom configurations are available upon request
